TXT 300 RAGA REPLICA 306 Parts catalogue : Page 22

          N    DESCRIPCION / DESCRIPTION                                                250 / 280 / 300   Cant.
 1   MULTIFUNCIÓN TRIAL / TRIAL MULTIFUNCTION                                  ET600002808        1
 7   BOMBILLA 12V 1,2-9W / 12V 1,2-9W BULB                                      L300123           3
 9   SOPORTE CUENTA KM. / KM. COUNTER SUPPORT                                 BT280634045         1
12 CTO. CLAXON PE40065G11 / HORN ASSY                                           L300105           1
13 TORNILLO ESPECIAL 6X14 / 6X14 SPECIAL SCREW                                  T0206014          1
14 REGULADOR ALTERNADOR / ALTERNATOR REGULATOR                                  L300031           1
15 INSTALACIÓN TRIAL / TRIAL INSTALLATION                                     ET10000RC2808       1
15A INSTALACIÓN HOMOLOGADA / HOMOLOGATED INSTALLATION                          ET100002808        1
16 BRIDA UNEX MEDIANA / UNEX CLAMP                                             BE25634009         3
17 ULS 6X16 NEGRO / 6X16 ULS BLACK BOLT                                        T0506016N          2
18 TUERCA CON ARANDELA M6 / M6 NUT WITH WASHER                                  T2206000          2
19 INTERMITENTE DERECHO TRASERO / RIGHT REAR INDICATOR                         BT280634018        1
20 BOMBILLA 12V 5-21W / 12V 5-21W BULB                                          L300116           1
21 CRISTAL FARO TRASERO HOMOLOGADO / HOMOL. REAR LIGHT CAP                     BP25734115         1
22 FARO PILOTO TRIAL HOMOLOGADO / HOMOL. TRIAL REAR LIGHT SET                  BP27534015         1
23 INTERMITENTE IZQUIERDO TRASERO / LEFT REAR INDICATOR                        BT280634019        1
24 FARO PILOTO TRIAL / TRIAL REAR LIGHT SET                                   ET30000CT2811       1
25 TORNILLO ROSCA CHAPA 3.5X13 / BOLT 3.5X13                                    T0603513          3
26 LÁMPARA 12V3W BIFARO AM0518 / 12V 3W LAMP                                    L300119           1
27 TIRA ADHESIVA 45MM. CAJA FILTRO EC2003 / STICKER 45MM.                     BE250328039         2
29 BOBINA KOKUSAN IG3815 / KOKUSAN ELECTRIC COIL                               ET500002809        1
30 ALLEN 6X16 / ALLEN 6X16 BOLT                                                 T0306016          3
31 PIPA BUJÍA IB05EMH = BT27934000 / SPARK PLUG                                BT25934000         1
32 BUJÍA BPR5ES / SPARK PLUG                                                   M04012000          1
33 CTO. OPTICA RACING RAGA 2011                                               BT90000123011       1
34A CDI DIGITAL CU7510 TRIAL / TRIAL DIGITAL CDI                               MT280534007        1
37 CONMUTADOR LUZ TT-97 / LIGHT SWITCH                                         ET602012808        1
38 INTERMITENTE DERECHO DELANTERO / FRONT RIGHT INDICATOR                     BT280634018         1
39 TORNILLO PHILIPS ROSCA-CHAPA 6.3x16 NEGRO / 6.3X16 CLACK SCREW               T0706316          2
40 SOPORTE INTERMITENTE DELANTERO / FRONT INDICATOR SUPPORT                   BE250134017         2




                                                                    GAS GAS    Chasis 8
