TXT 125 PRO 218 Parts catalogue : Page 8

          N   DESCRIPCION / DESCRIPTION                                        125 / 280 / 300   Cant.
1   TUERCA SUPERIOR DIRECCIÓN TRIAL / NUT TOP STEERING AXLE           BT280210030        1
2   TUERCA NUT 956 RAPIDA M6 / M6 FAST NUT                             T2606000          5
3   TUERCA INFERIOR DIRECCIÓN TRIAL / NUT UNDER TOP CLAMP            BT280410029         1
4   GUARDAPOLVO COJINETES DIRECCIÓN / BEARING STEERING, DUST COVER   BEP250210026        1
5   COJINETE DIRECCIÓN URBXA 32004 / BEARING STEERING                BT280210008         2
6   EJE DIRECCIÓN TRIAL 2002 / AXLE STEERING                          BT280214003        1
7   TÓRICA DIRECCIÓN 37X2,5 ENDUPAMP 250 / O'RING STEERING           BEP250210012        1
8   ARANDELA REGLAJE BLANCA / WHITE WASHER                           BT280210026         1
9   ARANDELA 36X42X0.5 / 36X42X0.5 WASHER                              T4003642          2
10 ALLEN M6x25 / ALLEN SCREW M6x25                                     T0306025          7


12 CHASIS TRIAL / TRIAL FRAME                                         BT100002811        1
13 TIRANTE CILINDRO / BRACE CYLINDER                                 BT280110050         1
14 ULS 8X20 / 8X20 ULS                                                 T0508020          7
15 TUERCA AUTOBLOCANTE M-8 ALTA / SELF-LOCKING NUT M8 HIGH             T2108002          4
16 PLATINA INFERIOR TRIAL / FORK CLAMP (LOWER)                       BT20000013012       1
17 GOMAS RADIADOR A CHASIS / RADIATOR PROTECTOR RUBBER                 G220000           3
18 CTO. ESTRIBOS TXT PRO / JOINT STIRRUPS                            BT14000CT2808       1
19 PASADOR ESTRIBERA / SCREW                                           T0508045          2
20 MUELLE ESTRIBO IZQUIERDO / SPRING FOOTSTEP (LEFT)                   M100004           1
21 CASQUILLO ESTRIBO TRIAL-99 / BUSH FOOTSTEP                         BT27910006         2
22 TUERCA AUTOBLOCANTE M-8 BAJA (DIN 982) / NUT NYLOCK LOW             T2108001          2
23 MUELLE ESTRIBO DERECHO / SPRING FOOTSTEP, RIGHT                     M100003           1
24 ALLEN 10x85 / 10X85 ALLEN BOLT                                      T0301085          1
25 TUERCA AUTOBLOCANTE M10 BAJA / SPECIAL M10 NUT                      T2110001          1
26 TUERCA ESPECIAL M10 / SPECIAL M10 NUT                             BT280210069         1
27 ALLEN M10X140 ZINCADO 12.9 / SCREW, BOLT ALLEN M10X140              T0310140          1
28 GOMA PROTECTOR TRASERO MOTOR / REAR ENGINE PROT. RUBBER           BT280336029         1
29 GOMA PROTECTOR DELANTERO MOTOR / FRONT ENGINE PROT. RUBBER        BT280236030         1
30 CASQUILLO PROTECTOR CÁRTER / CHASIS TRIAL / BUSHING               BT280310883         2
31 PLACA PROTECCIÓN MOTOR / TRIAL ENGINE PROTECTOR PLATE             BT11500R3009        1
32 ULS 8X16 / ULS 8X16                                                 T0508016          2
33 SOPORTE CABALLETE TRIAL 2000 / SIDE STAND BRACKET SUPPORT         BT280712023         1




                                                                        Chasis 3
